OMICRON DIGITAL PRESSURE GAUGE AS313

Description & Features:





Simple 2 button operation
Reset to zero feature
Backlight turns on when on/off button is pressed
Option for display to remain continuously on
Peak pressure indication option
316L welded diaphragm seal
Rubber boot is standard
ASME B40.100 compliant
±1% accuracy (±0.5% optional for gauges up to 5,000 psi)
1 year warranty
Applications:
 Ideal for commercial and industrial application in both test measurement and general
 purpose installations.
 Specifications :



 Case Size  : 2.5” (63mm)
 Case Material  : ABS (IP64)
 Rubber Boot  : Silicone rubber (IP65)
 LCD Display  : 2” x 3/4” (48mm x 16mm)
 Connection  : 1/4” NPT 304SS
 Sensor  316L welded, Piezo
 Operating Life  : 1 million cycles
 Power Supply  : 2 x AAA battery (1.5V)
 Battery Life  : 2 yrs (auto shut-off mode)
 Power Mode  : Auto or manual shut-off
 Display Digits  : 4 digits to 5,000 psi
5 digits for 10,000 psi and 15,000 psi
 Resolution  : 1 digit
 Pressure Unit Selection  : psi, mHO, mmHg, mbar, kPa ranges 100 psi
psi, bar, kg/cm, MPa, atm ranges ! 160 psi
 Operation Mode  : Continuous process pressure reading or peak pressure reading
 Response Time  : 3 Hz display refresh rate
 Proof / Burst Pressure  : 200% / 300% FS
 Operating /
Storage Temperature
 : 14°F to 122°F (-10°C to 50°C)
-4°F to 167°F (-20°C to 75°C)
 Accuracy  : ±1% (±0.5% optional for gauges up to 5,000 psi)

Additional Information:

  • Minimum Order Quantity: 3091976 Number
  • Pay Mode Terms: T/T (Bank Transfer)







Omicron DIGITAL MANMETER KELLER LEO2

 Model   : LEO2
 Temperature  : 0 to 50°C
 Range : -1 to 700 bar
 Battery Life  : 1000 hours
 Accuracy  : ± 0.1% of F.S
 Output  : NIL



 Description :

 LEO 2 is a compact, micro-processor (ìP) controlled, highly accurate and versatile pressure measuring instrument with digital indication. The piezoresistive pressure transducer as the heart of the instrument has gone through extensive pressure- and temperature tests. Its characteristics arestored in the instruments internal EEPROM. The ìP of the LEO 2 reads the characteristic values and calculates therefrom the pressure to an accuracy of < 0,1 %FS at room temperature.


The pressure is measured twice per second and displayed. The top display indicates the actual pressure, the bottom display shows the Max.- or Min.- pressure since the last RESET.

LEO 2 has two operating keys. The left key is to turn the instrument on, to select the functions and the pressure units. The right key executes the selected function or unit. The right key is also used to switch between the Max.- and Min.-value.

 Specifications :



 Pressure Range  : -1…3 bar
 Resolution  : 1 mbar
 Overpressure  : 10 bar
 Number of Digits  : 5 Digit
 Accuracy RT (room temperature) *  : < 0,1 %FS
 Total Error Band (0…50 °C) *  : < 0,2 %FS
 Storage- / Operating Temperature  : -20…70 °C / 0…50 °C
 Compensated Temperature Range  : 0…50 °C
 Supply  : 3 V battery, type CR 2430
 Battery Life  : 1’000 hours continuous operation
 Pressure Connection  : 7/16”-20 UNF (adapter G 1/4” included)
 Protection, CEI 529  : IP 65
 Diameter x Height x Depth  : 59 x 95 x 32 mm
 Weight  : 125 g

 Additional Information:

  • Minimum Order Quantity: 3091976 Number
  • Pay Mode Terms: T/T (Bank Transfer)

Omicron Differential Pressure Switch DP930

Model  : DP930
Media  : Air / Gases
 Enclosure  : ABS
 Wetted Parts  : Silicone
 Range  : 0 to 4kPa
 Accuracy  : ±2% of F.S
 Electrical Rating  : 2A, 250V AC



Special Features :



 High Quality, Low-Cost
 Visual Set Point Indication
 Hassle-Free Field Adjustment Knob
 2% Repeatability



 Description :

 The DP930 Differential Pressure Switch is a low-cost easy to use switch for very low pressure applications. The switch can monitor positive, negative, or differential pressure and with an easy to adjust set point knob makes field set up and adjustment hassle free. The differential pressure switch includes a SPDT relay rated for 1A @ 250V and can be set as low as 0.08” w.c. (20 Pa)



 Specifications :



 Media  : Air and compatible gases
 Max Pressure  : 40” w.c. (10KPa)
 Temperature Limits  : 5 to 140° F (-15 to 60° C)
 Electrical Rating  : 2A @ 250 V
 Electrical Connectio  : Screw terminals
 Process Connection  : 3/16” I.D. flexible tubing
 Enclosure Rating  : NEMA 13 (IP 54)
 Weight  : 3.5 oz (100 g)
 Accessories  : 6 ft (1.8m) flexible tubing (2) Static pressure
  fittings Z type mounting bracket Mounting screws
 Repeatability  : 2%
 Deadband  : approximately 10% of max set point

 Additional Information:

  • Minimum Order Quantity: 1976 Number
  • Pay Mode Terms: T/T (Bank Transfer)

OMICRON Differential Pressure Gauge USA

 We are leading supplier and trader of OMICRON Differential Pressure Gauge USA. Kindly find below product details of Low Cost Galaxy Differential Pressure Gauge.



Product Details:

Pressure Range Model Number Pressure Range

Pa / kPa
0 – 0.25” S2000-60PA 0 – 60
0 – 0.5” S2000-125PA 0 – 125
0 – 1” S2000-250PA 0 – 250
0 – 2” S2000-500PA 0 – 500
0 – 3” S2000-750PA 0 – 750
0 – 4” S2000-1KPA 0 – 1
0 – 5” S2000-1.5KPA 0 – 1.5
0 – 6” S2000-2KPA 0 – 2
0 – 8” Zero Center
0 – 10” S2300-60PA 30 – 0 – 30
0 – 15” S2300-120PA 60 – 0 – 60
0 – 20” S2300-250PA 125 – 0 – 125
0 – 25” mm w.c.
0 – 30” S2000-6MM 0 – 6
0 – 50” S2000-10MM 0 – 10
0 – 100” S2000-25MM 0 – 25

Additional Information:



  • Minimum Order Quantity: 1976 Number
  • Pay Mode Terms: T/T (Bank Transfer)



OMICRON HIGHLY PRECISE DIGITAL MANOMETER KELLER LEX1

 Model  : LEX1
 Temperature  : 0 to 50°C
 Range   : -1 to 1000 bar
 Battery Life  : 2000 Hours
 Accuracy : ± 0.01% of F.S
 Output  : RS485 Optional



 Description :

 LEX 1 is a micro-processor controlled, accurate and versatile digital pressure measuring instrument with integrated Max.-/Min.-function for calibration and testing purposes.


The pressure is measured twice per second and displayed. The top display indicates the actual pressure, the bottom display shows the Max.- or Min.-pressure since the last RESET.

LEX 1 has two operating keys. The left key is to turn the instrument on, to select the functions and the pressure units. The right key executes the selected function resp. unit or serves to display the Max.- and Min.-value.

 Specifications :



 Pressure Range  : -1…2 bar
 Resolution  : 0,1 mbar
 Overpressure  : 3 bar
 Number of Digits  : 5 Digit
 Accuracy (10…30 °C) *  : 0,05 %FS
 Precision *  : 0,05 %FS
 Precision optional (≥ 20 bar) *  : 0,025 %FS / 0,01 %FS
 Storage- / Operating Temperature  -10…60 °C / 0…50 °C
 Compensated Temperature Range  : 0…50 °C
 Supply  : 3 V battery, type CR 2430
 Battery Life  : 2000 hours continuous operation
 Pressure Connection  : G1/4”
 Protection  : IP65
 Diameter x Height x Depth  : 76 x 118 x 42 mm
 Weight  : 210 g

Additional Information:

  • Minimum Order Quantity: 1976 Number
  • Pay Mode Terms: T/T (Bank Transfer)

OMICRON HIGH ACCURACY DIGITAL PRESSURE GAUGE VE100

 Model  : VE100
 Temperature  : 0 to 50°C
 Range  : -1 to 700 bar
 Battery Life  : 1000 Hours
 Accuracy  : ± 0.075% of F.S
 Output  : Optional



 Description :

 VE100 is a micro-processor controlled, accurate and versatile digital pressure measuring instrument with integrated Max.-/Min.-function for calibration and testing purposes.


The pressure is measured twice per second and displayed. The top display indicates the actual pressure, the bottom display shows the Max.- or Min.-pressure since the last RESET.

VE100 has three operating keys. The left key is to turn the instrument on, to select the functions and the pressure units. The right key executes the selected function resp. unit or serves to display the Max.- and Min.-value.

 Specifications :



 Pressure Range  : -1…700 bar
 Resolution  : 0,1 mbar
 Overpressure  : 2X
 Number of Digits  : 4 1/2 Digit
 Accuracy (10…30 °C) *  : 0.075 %FS
 Precision *  : 0.075 %FS
 Precision optional (≥ 20 bar) *  : 0.05 %FS / 0.01 %FS
 Storage- / Operating Temperature  -10…60 °C / 0…50 °C
 Compensated Temperature Range  : 0…50 °C
Supply  : 1.5 V battery * 5
 Battery Life  : 1000 hours continuous operation
 Pressure Connection  : G1/4”
 Protection  : IP65
 Diameter x Height x Depth  : 76 x 118 x 42 mm
 Weight  : 210 g



OMICRON MEGNAHELIC GAUGE

 SpecificationBrandOMICRONMODELH2300-60PaRANGE-30 TO 30 PASCALSDELIVERY TIME1-2 WEEKSDescription

Product Code :  T/P/MHG/OMI/030/001

* RANGE : -30 TO 30 PASCALS
* MODEL : H2300-60Pa

Additional Information:

  • Minimum Order Quantity: 786 Number
  • Pay Mode Terms: T/T (Bank Transfer)

OMICRON DIGITAL PRESSURE GAUGE AS312

 Model  : AS312
 Temperature   : -10 to 50°C
 Range   : 0 to 700 bar
 Battery Life  : 2000 Hours
 Accuracy : ± 0.5% of F.S
 Output : NIL



 Description :

 The AS312 series is a media isolated digital pressure gauge featuring multiple measurement units, min/max readings, selectable tare/zero and an automatic power

off to conserve battery power. Also, a backlight provides improved visibility under marginal lighting conditions.

The AS312 will operate with any liquid or gas that is compatible with 17-4PH stainless steel. Please consult the factory for other available wetted materials.

The design of this one-piece sensing element contains no silicone oil, welds or internal O-rings. The AS312 is ideal for oxygen service, hydrogen* tanks and other critical applications where fluid filled gauges cannot be used.

 Specifications :



 Display Update Rate  : 2 samples per second
 Power  : 9 Volt Alkaline Battery
 Automatic Power Off  : 1 Hour
 Battery Life  : 2000 Hours Operation (typical)
 Protection Rating  : NEMA 4, IP 65
 Instrument Case  Poly carbonate



 Performance @ 25°C (77°F) :



 Pressure Range  : A number of preset ranges are available
 Measurement Units  : PSI, BAR, kg/cm, ATM, InH20, InHg
 Accuracy  : <±0.5% BFSL (Includes Non-linearity,
  Hysteresis and Non-repeatability)
 Stability (1 year)  : ±0.25% FS (typical)
 Over Range Protection  : 2X Rated Pressure
 Burst Pressure  : 5X or 20,000 PSI whichever is less
 Pressure Cycles  : >100 Million



 Environmental Data



 Temperature
 Media  : -55 to 125°C (-67 to 257°F)
 Operating (Ambient)  : -10°C to 70°C (14°F to 158°F)
 Storage  : -10°C to 85°C (14°F to 185°F)
 Thermal Limits
 Compensated Range  : 0°C to 55°C (32°F to 131°F)
 TC Zero  : <±1.5% of FS
 TC Span  : <±1.5% of FS

 Additional Information:

  • Minimum Order Quantity: 3091976 Number
  • Pay Mode Terms: T/T (Bank Transfer)
  • Port of Dispatch: BY ORDER

Dwyer 628-06-GH-P1-E4-S1 Pressure Transmitter 0-5 PSI

 Product Details:

Minimum Order Quantity 5 Piece
Model Number/Name 628-06-GH-P1-E4-S1
Measuring Rate 0-5 psi
Steel Grade Stainless Steel
Automation Grade Manual
Material Grade Stainless Steel
Condition New
Measuring Ranges 0-5 psi
Temperatures 200
Minimum Order Quantity 12 No
Brand DWYER USA

Dwyer 628-06-GH-P1-E4-S1 PRESSURE TRANSMITTER 0-5 PSI

Dwyer 628-06-GH-P1-E4-S1 PRESSURE TRANSMITTER 0-5 PSIG

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for deta



Additional Information:

  • Production Capacity: http://www.dpengineers.in
  • Delivery Time: http://www.dpengineer.in
  • Packaging Details: http://www.dpengineerindia.com

Dwyer 628-07-GH-P3-E4-S1 Pressure Transmitter 0-15 PSIG



Product Details:
Minimum Order Quantity 10 Number
Model Number/Name SERIES 626 & 628
Measuring Rate DWYER 628-07-GH-P3-E4-S1
Automation Grade Manual
Range 0-15 PSIG
Condition New
Measuring Ranges 0-15 PSIG
Usage/Application Irrigation equipment
Applications PTO systems
Response Time 300 ms
Application Pumping systems
Brand Dwyer USA
Product Weight 10 oz (283 g)

Dwyer 628-07-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-15 PSIG

Dwyer 628-07-GH-P3-E4-S1 Industrial 316 SS Pressure Transmitter, 0-15 psig
MORE ABOUT THIS ITEM

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for deta



Additional Information:

  • Production Capacity: http://www.dpengineerindia.com
  • Delivery Time: http://www.dpengineersindia.in
  • Packaging Details: http://www.dpengineers.info





Dwyer 628-07-GH-P3-E1-S1 PRESSURE TRANSMITTER 0-15 PSIG



Product Details:
Minimum Order Quantity 10 Number
Model Number/Name SERIES 626 & 628
Measuring Rate DWYER 628-07-GH-P3-E4-S1
Automation Grade Manual
Weight 10 oz (283 g)
Range 0-15 PSIG
Condition New
Measuring Ranges 0-15 PSIG
Usage/Application Irrigation equipment
Applications PTO systems
Response Time 300 ms
Application Pumping systems
Brand Dwyer USA
Product Weight 10 oz (283 g)

Dwyer 628-07-GH-P3-E1-S1 PRESSURE TRANSMITTER 0-15 PSIG
MORE ABOUT THIS ITEM

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for deta



Additional Information:

  • Production Capacity: http://www.dpengineers.info
  • Delivery Time: http://www.dpengineersindia.in
  • Packaging Details: http://www.dpengineer.co.in



Dwyer 628-13-GH-P1-E7-S1 Pressure Transmitter 0-300 PSIG



 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name 628-13-GH-P1-E7-S1
Measuring Rate 0-300 PSIG
Automation Grade Manual
Weight 10 oz (283 g)
Range 0-300 Psig
Condition New
Measuring Ranges 0-300 PSIG
Usage/Application PTO systems
Applications Pumping systems
Response Time 300 ms.
Application Booster stations
Brand DWYER USA
Net Weight 10 oz (283 g).
Product Weight 10 oz (283 g).

Dwyer 628-13-GH-P1-E7-S1 PRESSURE TRANSMITTER 0-300 PSIG

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.

A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineer.co.in
  • Delivery Time: http://www.dpengineer.in
  • Packaging Details: http://www.dpengineers.in



Dwyer 628-70-GH-P3-E4-S1 Pressure Transmitter 0- 2 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name 628-70-GH-P3-E4-S1
Measuring Rate 0-2 Bar
Automation Grade Manual
Weight 10 oz (283 g)
Range 0-2 Bar
Condition New
Measuring Ranges 0-2 Bar
Usage/Application Irrigation equipment
Applications Hydraulic
Response Time 300 ms.
Application Compressors
Brand DWYER USA
Net Weight 10 oz (283 g).
Series 626 & 628

Dwyer 628-70-GH-P3-E4-S1 PRESSURE TRANSMITTER 0- 2 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineers.co.in
  • Delivery Time: http://www.dpengineersindia.com
  • Packaging Details: http://www.dpengineersindia.in



Dwyer 628-75-GH-P3-E1-S1 Pressure Transmitter 0-10 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name DWYER 628-75-GH-P3-E1-S1
Measuring Rate 0-10 Bar
Automation Grade Manual
Weight 10 oz (283 g)
Range 0-10 Bar
Condition New
Measuring Ranges 0-10 Bar
Usage/Application Irrigation equipment
Applications Hydraulic
Response Time 300 ms.
Application Irrigation System Pressure
Brand DWYER USA
Net Weight 10 oz (283 g).
Series 626 & 628

Dwyer 628-75-GH-P3-E1-S1 PRESSURE TRANSMITTER 0-10 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.

Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.

Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic

MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.

A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineersindia.in
  • Delivery Time: http://www.dpengineers.info
  • Packaging Details: http://www.dp-engineers.com



Dwyer 628-90-GH-P3-E4-S1 Pressure Transmitter 0-16 Bar

 Product Details:

Minimum Order Quantity 10 Piece
Brand DWYER USA
Application Booster stations
Product Weight 10 oz (283 g)
Response Time 300 ms.
Usage/Application PTO systems
Model Number/Name Dwyer 628-90-GH-P3-E4-S1
Automation Grade Manual
Measuring Ranges 0-16 BAR
Condition New
Measuring Rate 0-16 BAR
Net Weight 10 oz (283 g).
Applications Pumping systems

Dwyer 628-90-GH-P3-E4-S1 Pressure Transmitter 0-16 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.

A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineers.in
  • Delivery Time: http://www.dpengineer.in
  • Packaging Details: http://www.dpengineers.co.in



Dwyer 628-07-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-15 PSIG

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name 628-07-GH-P3-E1-S1
Material 316L stainless steel
Measuring Rate 0-15 PSIG
Automation Grade Manual
Condition New
Measuring Ranges 0-15 PSIG
Usage/Application Booster stations
Response Time 300 ms.
Application PTO systems
Brand Dwyer USA
Warranty yes
Product Weight 10 oz (283 g)

Dwyer 628-07-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-15 PSIG
MORE ABOUT THIS ITEM

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for deta



Additional Information:

  • Production Capacity: http://www.dpengineersdelhi.co.in
  • Delivery Time: http://www.dpengineers.co.in
  • Packaging Details: http://www.dpengineerindia.in



Dwyer 628-07-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-15 PSIG

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name 628-07-GH-P3-E1-S1
Material 316L stainless steel
Measuring Rate 0-15 PSIG
Automation Grade Manual
Condition New
Measuring Ranges 0-15 PSIG
Usage/Application Booster stations
Response Time 300 ms.
Application PTO systems
Brand Dwyer USA
Warranty yes
Product Weight 10 oz (283 g)

Dwyer 628-07-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-15 PSIG
MORE ABOUT THIS ITEM

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for deta



Additional Information:

  • Production Capacity: http://www.dpengineersdelhi.co.in
  • Delivery Time: http://www.dpengineers.co.in
  • Packaging Details: http://www.dpengineerindia.in



Dwyer 628-75-GH-P3-E4-S1 Pressure Transmitter 0-10 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name DWYER 628-75-GH-P3-E4-S1
Measuring Rate 0-10 BAR
Automation Grade Manual
Accuracy 1.0% FS
Condition New
Measuring Ranges 0-10 BAR
Usage/Application Submersible pump control
Applications Irrigation equipment
Response Time 300 ms
Application Pumping systems
Brand DWYER USA
Net Weight 10 oz (283 g)

Dwyer 628-75-GH-P3-E4-S1 PRESSURE TRANSMITTER 0-10 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dp-engineers.com
  • Delivery Time: http://www.dpengineerindia.in
  • Packaging Details: http://www.dpengineers.co.in

Dwyer 628-81-GH-P3-E1-S1 Pressure Transmitter 0-40 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name Dwyer 628-81-GH-P3-E1-S1
Measuring Rate 0-40 Bar
Automation Grade Manual
Accuracy 1.0% FS
Condition New
Measuring Ranges 0-40 Bar
Usage/Application Submersible pump control
Applications Irrigation equipment
Response Time 300 ms
Application Pumping systems
Brand DWYER USA
Net Weight 10 oz (283 g)

Dwyer 628-81-GH-P3-E1-S1 PRESSURE TRANSMITTER 0-40 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineers.co.in
  • Delivery Time: http://www.dpengineersdelhi.co.in
  • Packaging Details: http://www.dp-engineers.com

Dwyer 628-81-GH-P3-E4-S1 Pressure Transmitter 0-40 PSIG

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name DWYER 628-81-GH-P3-E4-S1
Measuring Rate 0-40 PSIG
Automation Grade Manual
Condition New
Usage/Application Irrigation equipment
Response Time 300 ms
Application Submersible pump control
Brand DWYER USA
Warranty Yes
Product Weight 10 oz (283 g)

Dwyer 628-81-GH-P3-E4-S1 Pressure Transmitter 0-40 PSIG

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details



Additional Information:

  • Production Capacity: http://www.dpengineers.co.in
  • Delivery Time: http://www.dpengineersdelhi.co.in
  • Packaging Details: http://www.dpengineerindia.in

Dwyer 628-82-GH-P3-E4-S1 Pressure Transmitter 0-70 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name DWYER 628-82-GH-P3-E4-S1
Measuring Rate 0-70 BAR
Steel Grade 316L SS.
Automation Grade Manual
Material Grade Type 316L SS.
Range 0-70 BAR
Condition New
Usage/Application Irrigation equipment
Response Time 300 ms.
Application Industrial process monitoring
Brand DWYER USA
Product Weight 10 oz (283 g).

Dwyer 628-82-GH-P3-E4-S1 Pressure Transmitter 0-70 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dp-engineers.com
  • Delivery Time: http://www.dpengineer.info
  • Packaging Details: http://www.dpengineers.info

Dwyer 628-87-GH-P3-E1-S1 Pressure Transmitter 0-500 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 628-87-GH-P3-E1-S1
Material Type 316L SS.
Measuring Rate 0-500 BAR
Steel Grade Type 316L SS.
Automation Grade Manual
Material Grade Type 316L SS
Packing Size 1
Condition New
Measuring Ranges 0-500 BAR
Process Connection 1/4 Inch male or female NPT and BSPT.
Usage/Application Industrial process monitoring
Applications Compressors
Range Of Product 0-500 BAR
Response Time 300 ms.
Service Compatible gases and liquids
Mounting Orientation Mount in any position
Application Industrial process monitoring
Brand DWYER USA
Net Weight 10 oz (283 g).
Product Weight 10 oz (283 g).

Dwyer 628-87-GH-P3-E1-S1 Pressure Transmitter 0-500 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineer.info
  • Delivery Time: http://www.dp-engineers.com
  • Packaging Details: http://www.dpengineerindia.in

Dwyer 628-91-GH-P3-E4-S1 Pressure Transmitter 0-6 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 628-91-GH-P3-E4-S1
Material Type 316L SS.
Measuring Rate 0-6 BAR
Automation Grade Manual
Material Grade Type 316L SS.
Weight 10 oz (283 g).
Range 0-6 BAR
Condition New
Usage/Application Compatible gases and liquids
Applications Industrial process monitoring
Service Gases and Liquids.
Application Compressors
Brand DWYER USA
Product Weight 10 oz (283 g).

Dwyer 628-91-GH-P3-E4-S1 Pressure Transmitter 0-6 Bar
Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs
The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.
The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.
 Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.
Product Applications
CompressorsPumping SystemsIrrigation System PressureIndustrial Process Monitoring Hydraulic
MORE ABOUT THIS ITEM
Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.
A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.


Additional Information:

  • Production Capacity: http://www.dpengineers.info
  • Delivery Time: http://www.dpengineersindia.in
  • Packaging Details: http://www.dpengineerindia.com

Dwyer 628-95-GH-P1-E1-S1 Pressure Transmitter 0-600 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 628-95-GH-P1-E4-S1
Material Type 316L SS.
Measuring Rate 0-600 BAR
Packaging Type 1
Automation Grade Manual
Material Grade Type 316L SS
Packing Size 1
Weight 10 oz (283 g).
Range 0-600 BAR
Condition New
Measuring Ranges 0-600 BAR
Usage/Application Compatible gases and liquids
Applications Compressors
Connection Available 1/4 Inch male or female NPT and BSPT.
Range Of Product 0-600 BAR
Service Gases and Liquids.
Application Industrial process monitoring
Brand DWYER USA
Net Weight 10 oz (283 g).
Product Weight 10 oz (283 g).


Dwyer 628-95-GH-P1-E1-S1 Pressure Transmitter 0-600 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.

Dwyer 628-95-GH-P1-E4-S1 Pressure Transmitter 0-600 Bar

 Product Details:

Minimum Order Quantity 5 Number
Automation Grade Manual
Measuring Ranges 0-600 BAR
Measuring Rate 0-600 BAR
Packaging Size 1
Steel Grade Type 316L SS
Material Grade Type 316L SS
Connection Available 1/4 Inch male or female NPT and BSPT
Range Of Product 0-600 BAR
Brand DWYER USA
Application Industrial process monitoring
Product Weight 10 oz (283 g).
Usage/Application Compatible gases and liquids
Net Weight 10 oz (283 g).
Applications Compressors
Weight 10 oz (283 g).
Condition New
Range 0-600 BAR
Material Type 316L SS.
Model Number/Name DWYER 628-95-GH-P1-E4-S1
Service Gases and Liquids.

Dwyer 628-95-GH-P1-E4-S1 Pressure Transmitter 0-600 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details



Additional Information:

  • Production Capacity: http://www.dpengineersdelhi.co.in
  • Delivery Time: http://www.dpengineers.co.in
  • Packaging Details: http://www.dpengineerindia.in

Dwyer 628-76-GH-P1-E4-S5 Pressure Transmitter 0-12 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 628-76-GH-P1-E4-S5
Material Type 316L SS.
Measuring Rate 0-12 BAR
Automation Grade Manual
Material Grade Type 316L SS
Packing Size 1
Weight 10 oz (283 g).
Condition New
Measuring Ranges 0-12 BAR
Usage/Application Industrial process monitoring
Applications Compatible gases and liquids
Response Time 300 ms.
Service Gases and Liquids.
Application Compressors
Brand DWYER USA
Net Weight 10 oz (283 g).

Dwyer 628-76-GH-P1-E4-S5 Pressure Transmitter 0-12 Bar

Series 626 & 628 Industrial Pressure Transmitter

Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineer.info
  • Delivery Time: http://www.dpengineersindia.in
  • Packaging Details: http://www.dpengineerindia.com

Dwyer 174777-00 Pressure Transmitter 0-21 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 174777-00
Material Type 316L SS.
Measuring Rate 0-21 Bar
Packaging Size 1
Automation Grade Manual
Material Grade Type 316L SS.
Weight 10 oz (283 g).
Mounting Type Type 316L SS.
Condition New
Measuring Ranges 0-21 Bar
Process Connection 1/4 Inch male or female NPT and BSPT.
Usage/Application Compatible gases and liquids
Response Time 300 ms.
Application Compatible gases and liquids
Brand DWYER USA
Packing Type 1
Product Weight 10 oz (283 g).

Dwyer 174777-00 Pressure Transmitter 0-21 Bar
Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs
The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.
The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.
Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications
CompressorsPumping SystemsIrrigation System PressureIndustrial Process MonitoringHydraulic

MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.
 A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.


Additional Information:

  • Production Capacity: http://www.dpengineerindia.com
  • Delivery Time: http://www.dpengineer.co.in
  • Packaging Details: http://www.dpengineer.in

Dwyer 174779-00 Pressure Transmitter 0-400 Bar

 Product Details:

Minimum Order Quantity 10 Number
Model Number/Name DWYER 174779-00
Measuring Rate 0-400 BAR
Packaging Size 1
Steel Grade Type 316L SS.
Automation Grade Manual
Material Grade Type 316L SS.
Weight 10 oz (283 g).
Range 0-400 BAR
Condition New
Measuring Ranges 0-400 BAR
Usage/Application Industrial process monitoring
Range Of Product 0-400 BAR
Response Time 300 ms.
Application Compatible gases and liquids
Brand DWYER USA
Net Weight 10 oz (283 g).

Dwyer 174779-00 Pressure Transmitter 0-400 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineer.co.in
  • Delivery Time: http://www.dpengineers.info
  • Packaging Details: http://www.dpengineer.info

Dwyer 628-83-GH-P3-E4-S1 Pressure Transmitter 0-100 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name DWYER 628-83-GH-P3-E4-S1
Material Type 316L SS.
Automation Grade Manual
Material Grade Type 316L SS.
Range 0-100 BAR
Condition New
Usage/Application Industrial process monitoring
Applications Irrigation equipment
Response Time 300 ms.
Service Gases and Liquids
Brand DWYER USA
Net Weight 10 oz (283 g).

Dwyer 628-83-GH-P3-E4-S1 Pressure Transmitter 0-100 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.

 A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineer.info
  • Delivery Time: http://www.dp-engineers.com
  • Packaging Details: http://www.dpengineerindia.in

Dwyer 628-85-GH-P3-E1-S1 Pressure Transmitter 0-200 Bar

 Product Details:

Minimum Order Quantity 5 Number
Model Number/Name WYER 628-85-GH-P3-E1-S1
Material Type 316L SS.
Packaging Size 1
Steel Grade 316L SS.
Automation Grade Manual
Material Grade 316L SS.
Range 0-200 BAR
Condition New
Measuring Ranges 0-200 BAR
Modle DWYER 628-85-GH-P3-E1-S1
Usage/Application Pumping systems
Applications Irrigation equipment
Response Time 300 ms.
Service Compatible gases and liquids.
Application Irrigation equipment
Brand DWYER USA
Net Weight 10 oz (283 g).
Product Weight 10 oz (283 g).

Dwyer 628-85-GH-P3-E1-S1 Pressure Transmitter 0-200 Bar

Series 626 & 628 Industrial Pressure Transmitter
Complete Offering of Ranges, Connections and Outputs

The SERIES 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X (IP66) stainless steel general purpose housing or cast aluminum conduit housing.

The SERIES 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.



Note: The standard conduit housing (-CH) has been phased out, see the conduit box housing (-CB) for the replacement model.


Product Applications

  • Compressors
  • Pumping Systems
  • Irrigation System Pressure
  • Industrial Process Monitoring
  • Hydraulic


MORE ABOUT THIS ITEM

Ideal for OEM and process applications where ±1% full-scale accuracy is required. Transmitters feature a stainless steel housing and 316 stainless steel oil-filled sensor. The corrosion-resistant 316L stainless steel wetted parts allow these transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals in compressors, irrigation equipment, and process monitoring.



A variety of optional outputs, process connections and electrical terminations are available; contact an Application Specialist for details.



Additional Information:

  • Production Capacity: http://www.dpengineerindia.in
  • Delivery Time: http://www.dpengineers.co.in
  • Packaging Details: http://www.dpengineersdelhi.co.in

Series 251 - Wet/Wet Differential Pressure Transmitter

 Product Details:

Brand Sensocon USA Series 251

Series 251 - Wet/Wet Differential Pressure Transmitter
• 0.25% Accuracy

• 316 Stainless Steel construction

• 1000 PSI working pressure

• 5:1 Turn down

• Certificate of Calibration

The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.
Model Number Range
251-01 0 - 5 PSI ( 34.5 kPa )
251-02 0 - 10 PSI ( 68.9 kPa )
251-03 0 - 15 PSI ( 103 kPa )
251-04 0 - 30 PSI ( 206.8 kPa )
251-05 0 - 50 PSI ( 344.7 kPa )
251-06 0 - 100 PSI ( 689.5 kPa )
251-07 0 - 150 PSI ( 1034 kPa )
251-08 0 - 300 PSI ( 2068 kPa )
*Other ranges available upon request.


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)

Sensocon USA Wet Differential Pressure Transmitter Series 251

 Product Details:

Brand Sensocon USA Series 251

Sensocon USA Wet/Wet Differential Pressure Transmitter Series 251-01

The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.

Media compatibility:
Gas and Liquids compatible with 316SS
Accuracy:
+/- 0.25% F.S.
Over Pressure:
positive - 2x f.S.; negative-1x F.S.
Working Pressure:
1000 PSI (7MPa)
Temperature Limits:
Operating: -40° to 185°F (-40° to 85°C)
Compensated: -4° to 158°F (-20° to 70°C)
Thermal Effect:
+/- 0.028% FS/°F (0.050%FS/°C)
Stability:
+/- 0.5% FS/year
Power Supply:
12-30 VDC
Output Signal:
4-20 mA, 2-wire
Electrical Connetction:
mini DIN 43650
Response Time:
100 ms
Turn Down:
5:1
Enclosure Rating:
NEMA 4X (IP 65)
Process Connection:
1/4" NPT female, optional 1/4" G
Mounting Position Effect:
0.1% F.S., can be corrected by zero adjust

Model Number Range
251-01 0 - 5 PSI ( 34.5 kPa )


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)

Wet/Wet Differential Pressure Transmitter Series 251-02

 Product Details:

Brand Sensocon USA Series 251

Sensocon USA Wet/Wet Differential Pressure Transmitter Series 251-02

The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.

Media compatibility:
Gas and Liquids compatible with 316SS
Accuracy:
+/- 0.25% F.S.
Over Pressure:
positive - 2x f.S.; negative-1x F.S.
Working Pressure:
1000 PSI (7MPa)
Temperature Limits:
Operating: -40° to 185°F (-40° to 85°C)
Compensated: -4° to 158°F (-20° to 70°C)
Thermal Effect:
+/- 0.028% FS/°F (0.050%FS/°C)
Stability:
+/- 0.5% FS/year
Power Supply:
12-30 VDC
Output Signal:
4-20 mA, 2-wire
Electrical Connetction:
mini DIN 43650
Response Time:
100 ms
Turn Down:
5:1
Enclosure Rating:
NEMA 4X (IP 65)
Process Connection:
1/4" NPT female, optional 1/4" G
Mounting Position Effect:
0.1% F.S., can be corrected by zero adjust

Model Number Range
251-02 0 - 10 PSI ( 68.9 kPa )


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)

Wet Differential Pressure Transmitter Series 251-03

 Product Details:

Brand Sensocon


Sensocon USA Wet/Wet Differential Pressure Transmitter Series 251-03
The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.

Media compatibility:
Gas and Liquids compatible with 316SS
Accuracy:
+/- 0.25% F.S.
Over Pressure:
positive - 2x f.S.; negative-1x F.S.
Working Pressure:
1000 PSI (7MPa)
Temperature Limits:
Operating: -40° to 185°F (-40° to 85°C)
Compensated: -4° to 158°F (-20° to 70°C)
Thermal Effect:
+/- 0.028% FS/°F (0.050%FS/°C)
Stability:
+/- 0.5% FS/year
Power Supply:
12-30 VDC
Output Signal:
4-20 mA, 2-wire
Electrical Connetction:
mini DIN 43650
Response Time:
100 ms
Turn Down:
5:1
Enclosure Rating:
NEMA 4X (IP 65)
Process Connection:
1/4" NPT female, optional 1/4" G
Mounting Position Effect:
0.1% F.S., can be corrected by zero adjust

Model Number Range
251-03 0 - 15 PSI ( 103 kPa )

Wet Differential Pressure Transmitter Series 251-04

 Product Details:

Brand Sensocon

Sensocon USA Wet/Wet Differential Pressure Transmitter Series 251-04

The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.

Media compatibility:
Gas and Liquids compatible with 316SS
Accuracy:
+/- 0.25% F.S.
Over Pressure:
positive - 2x f.S.; negative-1x F.S.
Working Pressure:
1000 PSI (7MPa)
Temperature Limits:
Operating: -40° to 185°F (-40° to 85°C)
Compensated: -4° to 158°F (-20° to 70°C)
Thermal Effect:
+/- 0.028% FS/°F (0.050%FS/°C)
Stability:
+/- 0.5% FS/year
Power Supply:
12-30 VDC
Output Signal:
4-20 mA, 2-wire
Electrical Connetction:
mini DIN 43650
Response Time:
100 ms
Turn Down:
5:1
Enclosure Rating:
NEMA 4X (IP 65)
Process Connection:
1/4" NPT female, optional 1/4" G
Mounting Position Effect:
0.1% F.S., can be corrected by zero adjust

Model Number Range
251-04 0 - 30 PSI ( 206.8 kPa )


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)

Wet Differential Pressure Transmitter Series 251-06

 Product Details:

Brand Sensocon


Sensocon USA Wet/Wet Differential Pressure Transmitter Series 251-06

The Series 251 wet/wet differential pressure transmitter utilizes a double diaphragm sensor technology that outperforms standard double sensor products in accuracy, reliability and static operating pressure. This differential pressure sensing technology offers 0.25% accuracy with static operating pressures up to 1000 PSI. The Series 251 features 316 stainless steel construction designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration.

Media compatibility:
Gas and Liquids compatible with 316SS
Accuracy:
+/- 0.25% F.S.
Over Pressure:
positive - 2x f.S.; negative-1x F.S.
Working Pressure:
1000 PSI (7MPa)
Temperature Limits:
Operating: -40° to 185°F (-40° to 85°C)
Compensated: -4° to 158°F (-20° to 70°C)
Thermal Effect:
+/- 0.028% FS/°F (0.050%FS/°C)
Stability:
+/- 0.5% FS/year
Power Supply:
12-30 VDC
Output Signal:
4-20 mA, 2-wire
Electrical Connetction:
mini DIN 43650
Response Time:
100 ms
Turn Down:
5:1
Enclosure Rating:
NEMA 4X (IP 65)
Process Connection:
1/4" NPT female, optional 1/4" G
Mounting Position Effect:
0.1% F.S., can be corrected by zero adjust

Model Number Range
251-06 0 - 100 PSI ( 689.5 kPa )

© 2018 All rights reserved | Design by Designtoonz
Enquire now
